7 inch HMI

产品型号：CMTWSCGA0700I-LTA-C02

颜色：16bit RGB

外形尺寸：178.07*110.2*7.10mm

显示屏尺寸：164.90*100*.3.5mm

可视尺寸：154.21*85.92mm

分辨率：1024*600px

工作电压：4.65V~12V

工作温度：-20℃-70℃

存储温度：-30℃~80℃

触控类型：电容式

背光模式：LED

应用：工业设备、医疗设备、智能家居

Download

5寸多功能串口屏（HMI）

产品型号：CMTWSCGA0500I-LTA-C02

外形尺寸：130.5*85.5*14.0

显示屏尺寸：120.45*75.3*5.9

可视尺寸：108.0*65.2

FLASH存储器：16MB

颜色：16bit RGB

分辨率：800*480

触控类型：电容式

背光寿命:>3000H

用户存储：1024 bt

亮度：300nit

产品应用：工业自动化设备、医疗设备、智能家居

Download

7-inch intelligent TFT serial screen HMI

Model：MTWSCGA0700I-LTA-C01

Features： 1）Quickly implement interface design   2）Touch screen realizes HMI

3）65K true color display,wide viewing angle       4）Wide temperature

Specifications：

1、AA：154mm（H）*86mm（V）

2、Resolution: 1024(H) x 600mm(V)

3、Display Type: TFT

4、Brightness：250nit

5、Viewing angle：178°

6、Display color：65K (65536) color

7、Connector: RS232/ RS485

8、LCD 0perating Voltage: DC 5~15V, it is recommended to use 12V, 1A DC power supply

9、0perating Teperature: -20°C~70°C

10、Storage Teperature: -30°C~80°C

11、Backlight Type： LED

Product  Application：HMI applications such as new energy, smart home appliances, and vehicle panels

Download

7-inch TFT intelligent LCD display module

Product model: CMTWSVGA0700I-E3C-C01

Resolution: 1024 * 600

Interface: RJ45RS232

Working voltage: 11V~26V

Working temperature: -20 ° C~70 ° C

Wide viewing angle: Yes

External dimensions 185.9mmx109.5mmx25.4mm

Window: 154.21mm x 85.92mm

Touch screen: CTP

Brightness: 250cd/m ²

Product features: Full view, wide voltage, and support for PC download and USB drive upgrade

Download

8-inch TFT intelligent LCD display module

Product model: CMTSVGA0800I-E3R-C01

Resolution: 800x600

Interface: RS232

Working voltage: 6V~26V

Working temperature: -20 ° C~70 ° C

External dimensions: 217mmx166.5mm x 31.2mm

Window: 162mmx121.5mm

Touch screen: RTP

Product features: wide voltage, simultaneous support for PC download and USB drive upgrade

Download

128 x 64 dot matrix intelligent LCD module

Product model: CMM128640170I-Z0C-C01

Resolution: 128x64

Interface: RS232

Voltage: 2.8-3.3V

Display mode: FSTN, forward display, gray mode, semi transparent

Working temperature: -10 ℃~60 ℃

Storage temperature: -20 ℃~70 ℃

Perspective: 6:00

Product features: Supports both PC download and USB drive upgrade

Download

4-inch TFT intelligent LCD display module

Product model: CMTVGA0700I-E3A-C01

Resolution: 720x720

Interface: RS232

Working voltage: 5V

Working temperature: -20 ° C~70 ° C

Angle of view: Wide angle of view

External dimensions: 84mm * 86mm * 11.4mm

Window: 71.856mm * 70.176mm

Touch screen: CTP

Shell: plastic shell

Main applications: intelligent switches, temperature controllers, 86 box central control

Product features: high brightness, bright colors, integrated touch display, support for PC download, and support for secondary development

Download

4-inch intelligent LCD display module

Product model: CMM256S0400i-Z0C-C01

Resolution: 480x480

Interface: RS232

Working voltage: 5V

Working temperature: -20 ° C~70 ° C

Angle of view: Wide angle of view

External dimensions: 84mm * 86mm * 11.4mm

Window: 71.856mm * 70.176mm

Touch screen: CTP

Shell: plastic shell

Main applications: intelligent switches, temperature controllers, 86 box central control

Product features: Supports PC download and secondary development

Download

4.3 "TFT Intelligent LCD Display Module

Product model: CMTWHVGA0430I-E3R-C01

Resolution: 480x320

Interface: RS232

Working voltage: 6V~26V

Working temperature: -20 ° C~70 ° C

Boundary dimension: 139mmx97mmx27mm

Window: 95mmx53.8mm

Touch screen: RTP

Shell: plastic shell

Main applications: intelligent switches, temperature controllers, 86 box central control

Product features: high brightness, bright colors, integrated touch display, support for PC download, and support for secondary development

Download

2.1 inch TFT intelligent knob screen

Product model: CMTVGA0210I-Z0

Resolution: 480 * 480

Display mode: negative display

Interface: TTL

Working voltage: 5.0V

Perspective: 80/80/80/80

Touch screen: optional

Brightness: 300NITS

Overall dimensions: Φ seventy-eight point four zero × 23.50 (H)

Windows: Φ fifty-three point eight eight

Working temperature: -20 ℃~70 ℃

Storage temperature: -30 ℃~80 ℃

Product applications: coffee machines, microwave ovens, car knobs, etc

Product features: With LED ambient light, supporting secondary development

Download

1.39-inch AMOLED intelligent knob screen

Product model: OEM

Resolution: 454 * 454

Display mode: negative display in black

Interface: TTL

Working voltage: 3.3V

Perspective: 90/90/90/90

Touch screen: optional

Brightness: 350NITS

Boundary dimension: TBD

Windows: Φ thirty-five point four two

Working temperature: -30 ℃~80 ℃

Storage temperature: -40 ℃~85 ℃

Product applications: washing machines, ovens, air fryers, etc

Product features: high-end atmosphere, ultra-thin, ultra-low power consumption

Download

1.28-inch TFT intelligent knob screen

Product model: CMTQVGA0130I-Z0

Resolution: 240 * 240

Display mode: negative display in black

Communication method: TTL

Working voltage: 3.3V

Perspective: 80/80/80/80

Touch screen: optional

Brightness: 170NITS

Overall dimensions: Φ fifty × 30.20 (H)

Windows: Φ thirty-two point four zero

Working temperature: -20 ℃~70 ℃

Storage temperature: -30 ℃~80 ℃

Product applications: coffee machines, washing machines, etc

Product features: supports secondary development, low power consumption, and high cost-effectiveness

Download
